While air was still considered the number one enemy of speed before the war, engineers recognized its benefits in the mid-sixties in the search for ever higher cornering speeds. All kinds of tail units were used in an attempt to control and steer the airflow according to their own wishes. Part 2 of our history of racing car aerodynamics tells the story of the journey from the flow-optimized cigar to the downforce-generating wedge.

This article contains the following chapters

The first aerodynamic revolution: wings and spoilers
The second revolution: the wedge shape
The three-liter Formula 1 as a driver of aerodynamics
The third revolution: the wing car with ground effect
The fourth revolution: the vacuum cleaner
What remained of the wing car: the rear diffuser
2022 - The ground effect is back
Offshoots of aerodynamic developments for everyday cars
Epilogue

Estimated reading time: 10min

Preview (beginning of the article)

Cigars with a cut-off tip were the basic shape for single-seater racing cars until the 1970s. As in the pre-war period, the sole aim of the design was to minimize air resistance - albeit with a few interesting, forward-looking exceptions, as presented in Part 1 of this story. One of these exceptions reappeared in 1954: The air brake. The Mercedes-Benz 300 SLR was equipped with a scoop-like brake tailgate for Le Mans. In 1968, this concept appeared once again at the Indianapolis 500 on the STP gas turbine car. Since then, the air brake has gone quiet - not least because the development of increasingly effective disc brakes meant there was no longer any need for it.
